سنسور تشخیص سطح مایع SEN0204

۶۰۸,۰۰۰ تومان
سنسور تشخیص سطح مایع SEN0204

Specification

  • Operating Voltage (InVCC) : DC 5 ~ 24 v
  • Current consumption: 5 mA
  • Output voltage (high level) : InVCC
  • Output voltage (low level) : 0V
  • Output current: 1 ~ 50 mA
  • Response time: 500 ms

ماژول اندازه گیری سطح مایعات JSN-SR04T-2.0

۳۲۷,۰۰۰ تومان
ماژول اندازه گیری سطح مایعات JSN-SR04T-2.0

Specifications:

  • Pulse width output / Serial Output
  • Operating Voltage DC 3.0-5.5V
  • Working current Less than 8mA
  • Probe frequency 40KHz
  • Farthest range 600cm
  • Recent range 20cm
  • Distance accuracy +- 1cm
  • Resolution 1mm
  • Measuring angle 75 degree

ماژول تشخیص فاصله آلتراسونیک HY-SRF05

۵۶,۰۰۰ تومان
ماژول تشخیص فاصله آلتراسونیک HY-SRF05

Specifications

  • Trigger Pin Format: 10 uS digital pulse
  • Sound Frequency: 40 kHz
  • Echo Pin Output: 0-Vcc
  • Echo Pin Format: output is DIGITAL and directly proportional with range.
  • Measurement Range: 2cm to ~4.5m
  • Measurement Resolution: 0.3cm
  • Measurement Angle: up to 15 deg

ماژول آلتراسونیک اندازه گیری فاصله HC-SR04

۴۲,۰۰۰ تومان
ماژول آلتراسونیک اندازه گیری فاصله HC-SR04

Electric Parameter

  • Working Voltage DC 5 V
  • Working Current 15mA
  • Working Frequency 40Hz
  • Max Range 4m
  • Min Range 2cm
  • Measuring Angle 15 degree
  • Trigger Input Signal 10uS TTL pulse
  • Echo Output Signal Input TTL lever signal and the range in proportion

سنسور اثر انگشت ZFM-70

۱,۲۷۹,۰۰۰ تومان
سنسور اثر انگشت ZFM-70

Specification

  • DC3.8V-7.0V Interface UART (TTL logical level )
  • Working current Typical:<65mA Peak:<95mA
  • Matching Mode1:1 and1:N
  • Baud rate(9600*N)bps , N=1~12(default N=6)
  • Character file size 256 bytes
  • Image acquiring time<1s

شیلد تشخیص سیگنال قلب،ماهیچه،مغز

۱,۶۱۰,۰۰۰ تومان

شیلد تشخیص سیگنال قلب،ماهیچه،مغز

Features

  • Stackable headers up to 6 channels may be stacked and wired to A0-A6 analogue inputs.
  • Calibration signal generation by D4/D9 digital output.
  • Precise Trimmer potentiometer for calibration.
  • Input connector for normal or Active electrodes.
  • Works with both 3.3V and 5V Arduino boards.

ماژول تشخیص سیگنال عضله EMG

۱,۲۸۸,۰۰۰ تومان
ماژول تشخیص سیگنال عضله EMG

APPLICATIONS

  • Video games
  • Robots
  • Medical Devices
  • earable/Mobile Electronics
  • Powered Exoskeleton suit

Parameter :

  • Power Supply Voltage (Vs) :
  •      Min : ±3.5V
  •      TYP : ±5V
  •      Max : ±18V

سنسور ضربان قلب Heart Pulse Sensor

۱۵۲,۰۰۰ تومان
سنسور ضربان قلب Heart Pulse Sensor

DESCRIPTION

  • RED wire = +3V to +5V
  • BLACK wire = GND
  • PURPLE wire = Signal
  • Pulse Sensor Board
  • 24-inch Color-Coded Cable with Standard Male Headers
  • Ear Clip for Earlobe Heart Rate Measurement
  • Velcro Finger Strap
  • Transparent Stickers to Protect Sensor
  • 625" Diameter and 0.125" Thick

سنسور دریافت سیگنال مغز NeruSKY-TGAM

۳,۱۲۸,۰۰۰ تومان
سنسور دریافت سیگنال مغز NeruSKY-TGAM

Specs

  • 512 bits per second sampling frequency
  • 3-100Hz frequency range
  • ESD Protection: 4kV Contact Discharge; 8kV Air Discharge
  • Max Power Consumption: 15mA @ 3.3V
  • Operating voltage 2.97 ~3.63V

ماژول پالس اکسیمتر و سنسور ضربان قلب MAX30100

۱۳۸,۰۰۰ تومان
ماژول پالس اکسیمتر و سنسور ضربان قلب MAX30100

Absolute Maximum Ratings

  • VDD to GND : -0.3V to +2.2V
  • GND to PGND : -0.3V to +0.3V
  • x_DRV, x_LED+ to PGND : -0.3V to +6.0V
  • All Other Pins to GND : -0.3V to +6.0V
  • Output Short-Circuit Current Duration : Continuous
  • Continuous Input Current into Any Terminal : ±20mA
  • Continuous Power Dissipation (TA = +70°C)
  • OESIP (derate 5.8mW/°C above +70°C) : 464mW
  • Operating Temperature Range : -40°C to +85°C
  • Soldering Temperature (reflow) : +260°C
  • Storage Temperature Range : -40°C to +105°C

سنسور نوری ضربان قلب SFH7060

۱۶۱,۰۰۰ تومان
سنسور نوری ضربان قلب SFH7060
حسگر بیومتریک

Features

  • Multi chip package featuring three green, one red, one infrared emitter and one detector
  • Small package: (WxDxH) 7.2 mm x 2.5 mm x 0.9 mm
  • Light Barrier to block optical crosstalk
  • Improved geometry for optimized signal quality
