ماژول افزاینده و کاهنده ولتاژ LTC3780
ماژول افزاینده و کاهنده ولتاژ LTC3780
Parameters:
- Input Voltage: DC5 – 32 V;
- Output Voltage: DC1 V – 30 V continuously adjustable; the default 12 V Shipment
- Output Current: 10 A (Max), long term within 8 A
- Output Power: 80 W, peak 130, more than 80 W Please strengthen heat dissipation
- Output Ripple: 50mV (12 V turn to 12 V, 5 A Measured)
- Short circuit protection: Yes
- Input Reverse connection protection: No
- Output prevent reverse connection protection: No
- Operating Temperature Range: -45 ~ + 85 Centigrade
ماژول تغذیه کاهنده ولتاژ XL7015
ماژول تغذیه کاهنده ولتاژ XL7015
- 5 v to 80 v input voltage range wide;
- The output voltage from 5 v to 20 v adjustable;
- The minimum pressure drop 1 v.
- 0.8 A biggest switch current;
- Recommend the output power is less than 7 w;
- Shut off built-in overheating protection, output short circuit protection, over current protection;
- Good linear with load regulation;
- The board size: 16 mm * 44 mm;
