تستر و کنتور برق شهر P06S-20
تستر و كنتور برق شهر P06S-20
Specifications
- Model: P06S-20
- Name: 6 in 1 Voltage Meter
- Max. Power: 5000W
- Rated Power: 4400W
- Standby Power: <1W
- Max. Current: 20A
- Rated Power: 20A
- Voltage: 110~250V AC
- Voltage Accuracy: ±1%
- Current Accuracy: ±2%
- Power Accuracy: ±2%
- Size: Approx. 8.5 x 4.7 x 2.8cm / 3.35 x 1.85 x 1.1inch
- Panel Size: Approx. 5.45 x 9cm / 2.15 x 3.54inch
- Quantity: 1pc
- Weight: 79g
تعذیه سوئیچینگ 15 ولت 5 آمپر RPS-75-15
عذیه سوئیچینگ 15 ولت 5 آمپر RPS-75-15
specifications
- Manufacturer: MEAN WELL
- Product Category: Switching Power Supplies
- Product: Switching Supplies
- Output Voltage-Channel 1: 15 VDC
- Number of Outputs: 1 Output
- Output Power: 75 W
- Open Frame/Enclosed: Open Frame
- Input Voltage: 90 VAC to 264 VAC, 127 VDC to 370 VDC
- Output Current-Channel 1: 5 A
کنتور برق شهر P06S-100
كنتور برق شهر P06S-100
Specification
- Model: P06S-100
- Name: Power Monitor
- Rated power:100A/22000W
- Maximum current: 100A
- Working voltage: 80V-260V
- Test voltage: 50V-300V
- Frequency test range: 45V-65Hz
- Power test range:0.01W~22000W
- Power test range: 0.01W~9999kwh
- Voltage test range: 50V~300V
- Current test range:0.01~100A
کارت کنترل اینورتر شبه رزونانس EGT003-EG1611-EG2132
کارت کنترل اینورتر شبه رزونانس EGT003-EG1611-EG2132
Feature
- Adopt full bridge quasi resonance transformation structure, isolated DC-DC boost circuit
- Ultra-thin transformer design, high power density
- No heat sink is required for the front MOS tube
- Rated 1000W power output
- 24V inverter: Input voltage range: 20V ~ 30VDC ±0.5V
- 48V inverter: Input voltage range: 40V ~ 60VDC ±0.5V
ماژول افزاینده و کاهنده ولتاژ LTC3780
ماژول افزاینده و کاهنده ولتاژ LTC3780
Parameters:
- Input Voltage: DC5 – 32 V;
- Output Voltage: DC1 V – 30 V continuously adjustable; the default 12 V Shipment
- Output Current: 10 A (Max), long term within 8 A
- Output Power: 80 W, peak 130, more than 80 W Please strengthen heat dissipation
- Output Ripple: 50mV (12 V turn to 12 V, 5 A Measured)
- Short circuit protection: Yes
- Input Reverse connection protection: No
- Output prevent reverse connection protection: No
- Operating Temperature Range: -45 ~ + 85 Centigrade
