سروو موتور DM-S0306D
سروو موتور DM-S0306D
دانلود دیتاشیت
This DM-S0306D servo motor can run without limit, making it suitable for many applications such as wheels, rotors and other 360 ° applications. The servo has a torque of 3 kg at 4.8 V and a speed of 0.13 sec/60 degrees.
Features:
Standard Size Digital Servo with POM Gears 25T servo, 2BB
Torque Motor, 12bit Digital PCB
Operating Voltage: 4.8V~6V
Dead Band Width: 2usc
Interface: (JR)
Specifications:
Item No.: DM-S0306D
Speed: 0.13sec/60degree at (4.8v) 0.11sec/60degree at (6v)
Stall Torque: 3kg.cm.at (4.8v)
Size: 40.6 x 19.8 x 38.5mm
