ماژول تشخیص سیگنال عضله EMG
ماژول تشخیص سیگنال عضله
Three-lead Differential Muscle/Electromyography Sensor for Microcontroller Applications
MUSCLE SIGNAL SENSOR
FEATURES
- Small Form Factor (1inch X 1inch)
- Specially Designed For Microcontrollers
- Adjustable Gain – Improved R
- New On-board 3.5mm Cable Port
- Pins Fit Easily on Standard Breadboards
APPLICATIONS
- Video games
- Robots
- Medical Devices
- earable/Mobile Electronics
- Powered Exoskeleton suit
Parameter :
- Power Supply Voltage (Vs) :
- Min : ±3.5V
- TYP : ±5V
- Max : ±18V
- Gain Setting, Gain = 207*(X /1 kΩ) :
- Min : 0.01 Ω (0.002x)
- TYP : 50 kΩ (10,350x)
- Max : 100
- Output Signal Voltage (Rectified & Smoothed) :
- Min : 0V
- TYP : –
- Max : +Vs
- Differential Input Voltage :
- Min : 0 mV
- TYP : 2-5mV
- Max : +Vs/Gain
