ماژول غیر تماسی دما ZTP-115M
ماژول غیر تماسی دما
Applications
- Occupancy detection
- HVAC
- Appliance
- Microwave oven
Features
- Non-contact measurement
- Wider surface area measurement
- Small-size sensor package
- Included ambient temperature (thermistor) sensor for compensation
- High sensitivity
- Fast response time
- Low cost
- Analog output
Specifications
- Supply Voltage : Single Supply (+5V)
- Supply Current : Typical 2.7 mA
- Response Time : 0.3 ~ 0.6 seconds
- Temperature Range : -40°C ~ 145°C
- Operating Temperature : -20°C ~ 100°C
- Storage Temperature : -20°C ~ 120°C
- Thermopile Sensor : ZTP-115
- Mating Connector : JST Model EHR-3
- Form of electromagnetic wave
- Extends from 0.7 um -1000 um
- ‒ Near infrared: 0.7um – 2.5 um
- ‒ Intermediate infrared: 2.50 um – 25.0 um
- ‒ Far infrared: over 25.0 um
- Most IR sensors based on two regions … 3 – 5um and 8 – 12 um
